DC Power Supply
Model PS5006





  Introduction
The PS5006 industrial DC series PS2 switching power supply delivers precision power for all your application needs. Standard features include triple circuit protection, and nickel plated enclosure. Performance PC needs a powerful power supply. With iStar, you always have a good start!


  Features
- Nickel Plated Enclosure
- High Efficiency and Reliability
- 16ms Hold Up Time
- Active PFC
- Over Power Protection
- Over Voltage Protection
- Short Circuits Protection

 Specifications
 RoHS Compliance Version   Yes
 Output Power   400W
 Main Connector   20 Pin
 12v Connector   4-Pin
 Dimensions (W x H x D)   150 x 86 x 140 mm

Output

+3.3V

+5V

+12V

-12V

-5V

5Vsb

Max Load

20A

42A

14A

3A

1A

1A

Min Load

0.1A

2.5A

0.5A

-

-

-

Regulation

± 5%

± 5%

± 5%

± 10%

± 10%

± 5%

Ripple(mV)

50

50

100

150

150

100
