SAS / SATA JBOD : Part # SA4001


                                          4U Rackmount Storage Chassis ,15 SATA Hot-Swap bays, 19.7" depth
                                                                         with Riser Card and Three Cables


**Click on picture to enlarge

   FEATURES
  • 4U rack height.
  • Very cost effective storage subsystem.
  • 3 ports eSATA host interface (Silicon Image SiI3124 + SiI3726 Multipliers).
  • 1.5 Gb/s SATA I and 3 Gb/s SATA II host and drive support.
  • Supports up to fifteen 3.5" SATA-I or SATA-II disk drives, no drive size limit;
  • Excellent cooling system ensures the drives reliability;
  • Hot-swappable disk drive tray with special designed power-off and lock mechanism;
  • Monitor and alarm with temperature and fan-speed display
  • PCI-X/PCI card, eSATA cables, power supply, HDD mobile rack, backplane, all mounting screws for HDDs included
  • Support RAID 0, 1, 0+1, JBOD, RAID5 (Windows only)
  • Supports Windows, Linux, MAC


More photos (Click on the photos for enlarged views)




Host Controller
Included - Included - PCIe x8 4 port controller card

Optional Compatible controller - HighPoint RocketRAID 2314 Host Adapter, x4 PCIe, 4 port eSATA, support hardware RAID 5 under PC and Mac OS
Drivers & Utilities

More drivers for SiI3124



 SPECIFICATION
  Main features  4U, 15 x 3.5" HDD bays, SINGLE Expander, AC HRP, SATA
  Power Supply  650W 110V-240V pro-data power supply
  Drive Bay  10 x hot-swappable SATA slim drivebay
  Interface  3 ports eSATA host interface
  Cooling Fan

 120mm ball-bearing fan x 3,
 90mm ball-bearing fans x 3

  Maximum Storage Capacity  no limit on hard drive size
  Data speed  3 Gb/s
  RAID  Support Support RAID 0, 1, 0+1, JBOD, RAID5 (Windows only)
  O/S Supported  MAC OS, Linux, Windows NT, Windows 2000,
 Windows XP, Windows 2003, Windows Vista
  Dimensions (W x D x H)  19" x 19.7" x 7" (483mm x 500mm x 176mm)
  Temperature Range  Operating 41°F to 104°F (5°C to 40°C)
 Shipping -31°F to 167°F (-35°C to 75°C)
