1U Slotted Routing Cable Manager
Part#  CMA10

SKU#  SY- 1903-3-400-01


                                                                                     MADE IN THE USA

*click on photo for enlarged view

Built with narrow and wide fingers, the 1U Slotted Routing Cable Manager is a cross between the 1U Finger Duct Cable Manager, the D-Ring Cable Manager, and the Cable Routing Blanks. The narrow fingers allow for separation when routing cables between switches and patch panels, while the wide fingers help to retain cables during and after installation. For added protection and storage, a cover is also included to enclose the cables and create a clean look for your rack. Flanged fingers are an extra feature to help when routing cables, and to help contain cables should the cover be lost or temporarily removed. Rear cut outs allow cables to pass through the back of the unit – a great feature when mounting two units back to back. If mounting two units back to back, the 1U Finger Duct Cable Manager is another option for the front installation. Messy and unmanaged cables are no longer an issue with the 1U Slotted Routing Cable Manager.
  • Cable manager cover included
  • Wide and narrow fingers
  • Durable, steel construction
  • Rack-mountable with standard rack hardware
  • 19” EIA 310-D compliant
  • Made in the USA




Features
Cover Included   The easy, slide on cover helps to store and protect cables, and as an added bonus, will create a clean and sleek look for your rack.
Flanged Fingers   Flanged fingers help to contain cables when routing them through the slotted ducts. If the cover is ever lost, the flanges will also help to contain these cables.
No Mess Maintenance   Cables will now be organized in such a fashion that little effort is needed when having to locate or change a cable. Searching through a jungle of cables is no longer necessary, making maintenance and labor costs decrease as a result of this organization.
Durable Material   Constructed from steel and finished with a textured powder coat, this cable manager is more durable and rigid than plastic finger duct cable managers on the market.
Rounded Corners   All corners are rounded to avoid snagging or damaging cables, hands, and/or other devices.
Specifications
  • Width : 19"
  • Depth : 3.07"
  • Height : 1.73"
  • Material(s) : CRS (Cold Rolled Steel)
  • Color/Finish : Black Powder Coat Finish
  • Weight : 2.50 lbs.
Package Content
  • Qty 1 – 1U Slotted Routing Cable Manager
  • Qty 1 – Cable Manager Cover


More photos ( Click for enlarged views )


Optional Accessories
  Air Filters    Rack Mount LCD Monitors ( No Keyboard & KVM )
  Blank Panels    Rack Mount LCD Monitor Keyboard Optional KVM
  Bracket Supports    Rack Power Distribution Unit / Rackmount PDU
  Cable Management    Rack Mount Rails
  KVM Switches    Rack Mount Shelves
  Rack Mount Cooling Fans    Rack Mount Speakers
  Rack Display Mounting Brackets    Power Strips
  Rack Mount Drawers    Screw Bags
  Rack Mount Keyboard Drawers (No Monitor & KVM)    Vertical Mounting Rail
  Intelligent Cabinet Door Lock handle    Environmental Control Management

 Ordering Information

Part # Description
 CMA10
 Price : $28.80
1U Slotted Routing Cable Manager
