  9U Rackmount Chassis :  Part # RM9001
             a Rackmount chassis with 50-Bay Storage Server






                      19" Rackmount Standard
RoHs Compliance: Yes
Standard Drive Bays: 50 x 3.5” Hot-Swap Drive & 1 x 5.25” Drive
Color: Black and Silver
Motherboard Size: Support EATX M/B (Max. to 12" x 13")
Backplane mini SAS (SFF8087)
Hard Drive Interface: SAS/ SATA II
Cooling Units: 3x 120mm & 3x 80mm Cooling Fans
Expansion Slots: 7 Slots
Connector Port : 2 x USB Ports(Front)
Materials: Heavy-Duty Cold-Roll Steel
Materials of Main Chassis: Zinc-Plated with Bright Chromate
Material of Front Bezel: Texture-Coated
Material of Handle: Aluminum
Indicators: LEDs for Power ON/OFF, HDD Activity and Fan Failure
Switch: Power ON/OFF, System Reset, Mute
Dimensions: 19" x 15.75" x 27" (W x H x D)
Humidity: 5% - 95% Non-condensing

   Drawing Info                     Product Sheet






Introduction:
The RM9001 storage server series rackmount not only has the stylish appearance, but the functionality and flexibility make RM9001 series a new breed of storage server. As SAS and SATA technology has become a more cost effective solution, Synergy Global Technology Inc has taken a step forward to prepare the migration of new technology and provide the mini SAS backplane to support both latest SAS and SATA hard drives. We also provide redundant power supply to ensure total up time of mission critical server applications.

Features
• Fiber Optical Drive Tray Status Indicator
• Advance Thermal Cooling Design Optimizes Airflow
• 3x80mm Cooling Fans for Ventilation
• Mini SAS Backplane
• Front Access USB Connector
• Power + Fan Failure + HDD LED Indicator
• Power/Alarm Reset Switch
• Support EATX Motherboard
• Fully RoHS Compliance
• Two bottom drive bays can be dedicated for OS Redundancy


  For more pictures , click on the following for enlarged view:




Ordering information
Part Number  Description
RM9001-R150     9U Rackmount Chassis, 50 x 3.5" storage server w/ 1500W redundant P.S.
RM9001-R180     9U Rackmount Chassis, 50 x 3.5" storage server w/ 1800W redundant P.S.
RM9001-R200    9U Rackmount Chassis, 50 x 3.5" storage server w/ 2000W redundant P.S
