LCD1U15-03  -  $708 Only

Panel:  15" LCD panel     Display Type TFT / LCD active matrix color  Resolutions 1024 x 768 Brightness 250 cd/ m2 typical Scan Interval 3, 8, 15, 30sec MTBF 50,000 hours Keyboard 105-Key ALPS (R) mechanical keyboard , compatible to IBM PC/AT, PS/2 keyboard, support Windows function keys KVM Standard : 1 port KVM  Optional  :  8-port KVM Switch Dimension 19"(W) x 1.73"(H) x 20"(D)  / 483mm (W) x 508mm (D) x 44mm (H) Relative Humidity 5~85% Operating temp. 0  to 50 ºC Vibration 5-500Hz 1G RMS random Vibration

LCD1U15-03                            *click on the picture for enlarged view       User Manual

FEATURES :

• Standard 1U 19 inch rack mounting
• No software required - Computer selection via pushbuttons, hot keys or OSD (On-screen display)
• Hot plug-add or remove computer without the need to switch off power
• Supports  PS/2 & serial mouse
• Supports Miscrosoft IntelliMouse (Pro)
• Original Logitech (R) touchpad mouse
• Hot-key functions allow easy computer access
• Keyboard states automatically saved and restored when switching computers
• Operating system independent , transparent to all applications
• Plug & play system configuration
• Keyboard & mouse can be hot plugged at any time
• High VGA resolution 1600 x 1200 for KVM switch (but limited by LCD)
• DDC2B compatible
• Supports optional multimedia module and stereo speakers
• Compatible with  standard VGA / PS2 mouse
• Compatible with keyboard / Audio cables & connectors
• Front panel stainless steel handle.
• Built-in side railing for instant installation and easy access
• FOR LCD1U15-03-8KVM ONLY (i.e. the model with 8 PORT KVM SWITCHES) :    1. Quick View scan mode for monitoring selected computers    2. Cascade configuration expands system capability (Up to 64 PCs)                3. Auto-scan automatically selects computers sequentially

Power supply :

• 12V DC Input , includes Universal : 100V - 240V AC Input , 12V DC Output
  power supply adapter
• Optional - power adaptor 48V or 24V DC input available

 Ordering information :
