1U Rackmount 4K Monitor Keyboard Drawer with HDMI KVM and DP KVM Options
Model LCD1U19-33

Nova 1U Rack Mount 18.47" 4K UHD Widescreen Monitor Keyboard Drawer
Optional 4K HDMI KVM and DP KVM
TAA Compliant

4K UHD Rackmount KVM Console LCD1U19-33

Features

1U Rackmout 18.4" 4K ULTRA HD Wide Screen LCD KVM Console
3840x 2160 native resolution / 1.07B colors
1920x 1080 & 1920x 1200 resolution support
DisplayPort 1.2 video input with speakers / USB Keyboard mouse
Short Depth design of 18.1" ( 460 mm)
Built-in dual stereo speakers
Windows 104-key Keyboard with touchpad or trackball
TAA Compliant

Options

HDMI 2.0 Video Input
3G / HD / SD-SDI Broadcast-grade input + Speakers
4K HDMI KVM
DP KVM
Front USB hub port for device access
250V , 125V , 110V , 48V, 24V or 12V DC power

LCD Screen
Display Size	18.4"
Panel Type	4K UHD Ultra High Defination
Resolutions	Native Resolution up to 3840x 2160 @60Hz
Viewing Angle	89/89/89/89
Contrast Ratio	1000 : 1
Brightness	300 cd/m²
MTBF (hrs)	30,000
Colors	1.07B
Response Time	15 ms
Dot Pitch	0.1065 mm
Display Area	408.96H x 230.04V
Surface Treatment	Anti-glare
Surface hardness	3H
Console Port
DisplayPort	DP 1.2
Keyboard / Mouse	USB
Video OPTION
HDMI	HDMI 2.0 / HDCP 2.2
SDI	3G / HD / SD-SDI
Keyboard & Pointing Device
Model n / b	Windows Keyboard with Numeric Keypad & Touchpad OR Trackball
Power Supply
Input	Auto-sensing 100 to 240VAC, 50 / 60Hz
Environmental
Temperature	-20 to 70 Degree Celsius (Operation) -20 to 70 Degree Celsius (Storage)
Relative Humidity	10~90%, non condensing (Operation) 5~90%, non condensing (Storage)
Altitude	16,000 ft (Operating) 40,000 ftn(Non-Operating)
Shock	10G acceleration (11ms duration)
Vibration	10~300Hz 0.5G RMS random vibration
Mechanical
Product Dimension	Single Console: 17.4(W) x 18.1(D) x 1.73(H)inch / 442(W) x 460(D) x 44(H) mm Multi Port KVM Console: 17.4(W) x 22.8(D) x 1.73(H) inch / 442(W) x 580(D) x 44(H) mm
Product Weight	Single Console : 25.3lbs Multi Port KVM Console: 35.2lbs
Compliance
	FCC, CE CE / LVD & UKCA REACH RoHS3 / WEEE TAA Compliant

Free Ground Shipping. Learn More.

KVM Type	Number of User	Cascade Capacity	Number of KVM Port	Part Number	Data Sheet & User Manual
VGA Combo KVM / 1 User
DisplauPort KVM	1 Local User	N/A	1	LCD1U19-33-n ( touchpad)	Data Sheet User Manual
				LCD1U19-33-b ( trackball)
Optional KVM Switch	Number of User	Cascade Capacity	Number of KVM Port	Part Number	Data Sheet & User Manual for KVM Switch
4K KVM / HDMI KVM / 1 User
4K KVM / HDMI KVM	1 Local User	1 level	8	LCD1U19-33-8HD-n ( touchpad)	Data Sheet User Manual
				LCD1U19-33-8HD-b ( trackball)

Other Options

Part Number	Description
Optional Keyboard & Pointing Devices
-Sn	Change Windows Keyboard to SUN keyboard with touchpad
-Sb	Change Windows Keyboard to SUN keyboard with trackball
Optional Video Input
-HDMI	HDMI-2.0 + DP + Speaker
-SDI	3G-SDI + DP + Speaker
Optional Front USB Port
-UH	Front USB Port for device access * For Single Console Only
Optional DC Power
-DC12	Change to 12V DC power supply
-DC24	Change to 24V DC power supply
-DC48	Change to 48V DC power supply
-DC110	Change to 110V DC power supply
-DC125	Change to 125V DC power supply
-DC250	Change to 250V DC power supply
