Home >> Rackmount Keyboard Drawer / KVM Switch / KVM Extender >>

RACKMOUNT KEYBOARD DRAWER / KVM SWITCH /KVM Extender :
Part # LCDK1060

                           1U Rackmount Keyboard with 19" Travel Drawer , Front Lock ,
           with 2 consoles (Local + IP ) High Density CAT.5 KVM Over IP Switch : 32 port RJ-45
                               optional Trackball / Touchpad and & optional Gel Wrist Pad

Features

1U, standard 19" rackmount keyboard drawer
Lightweight construction
Lockable drawer to secure the keyboard & mouse
Five keyboard selections support multiple languages
Large padded wrist-rest for "d" & "t" style keyboard
Adjustable mounting brackets from 390 to 795 mm
Slide rails have fixed position to prevent movement of the keyboard
All mounting hardware included
Cascade for use up to 256 servers.
Name servers up to 16 characters long.
Scan mode – Monitor servers at intervals 5 to 99 seconds.
High Video Quality - Up To 1600x1200
Built-in microprocessor emulation for each port boots up process.
Support eight characters password protection and search PC server name.
Multi-platform – mix PCs, SUN Microsystems, IBM compatibles, HPs, Compaq and Dell.
Hot Pluggable - Add PCs or Remove Connected PCs for Maintenance without powering down the PS/2 KVM switch or PCs.
No Software Required - easy PC selection via On Screen Display Manual, Push Buttons, Hot Keys.

Front View of LCDK1060d

Keyboard User Manual

KVM User Manual

Click on the following photos for enlarged view :

5 KEYBOARD OPTIONS :


		*Details of Keyboard Options*

More Photos (click on the photos below for enlarged views ):

n : Notebook KB w/ touchpad d : Compact KB w/ trackball c : Cherry KB w/ trackball

b: Notebook KB w/ trackball t: Compact KB w/ touchpad Dimension Diagram

KVM Specification :

KVM Port
Number of ports :	32
Connector:	RJ-45
Connectivity:	USB type or PS/2 type dongle, up to 40 meter ( 130 feet)
Local Console
Graphic connector:	HDDB15-pin, VGA
Resolution:	Up to 1600x1200
Input device:	2 x USB type A for keyboard & mouse
IP Remote Console
Connector :	RJ45 ethernet
Resolution :	Up to 1600 x 1200
User management:	15-user login, 1 x active user
Network protocol:	DHCP / BOOTP / DNS
Security:	SSL v3, RSA, AES, HTTP / HTTPs, CSR
Browser:	IE, Firefox, Safari, Netscape
Others:	Serial port, virtual media via USB
Expansion :
	Up to 256 servers
Compatibility
Multi-platform:	Mix PCs, SUNs, IBMs, HPs, DELLs Server
Support:	Windows Vista, 2003 / XP / 2000, Linux, Netware, Unix
Power
Input:	100-240VAC, 50 or 60Hz, IEC type cord
Option DC :	12V/24V/48V DC input
Consumption :	Max. 25 Watt
Regulatory Approval
	FCC, CE
Environmental
Operating :	0 to 50"C
Storage:	-10 to 60-C
Relative humidity:	90%, non-condensing
Shock:	50G peak acceleration (11 ms, half-sine wave)
Vibration :	58~100Hz / 0.98G (11 min / cycle)

ACCESSORIES -

Part #	Description
LCD-A2001	USB dongle	Details
LCD-A2002	PS/2 dongle	Details
LCD-A1019	6ft cascade cable	Details

Ordering information

Part Number Description

LCDK1060-c 1U Rackmount Keyboard Drawer with Cherry keyboard and trackball , Lock, 2 Console (Local + IP ) CAT.5 IP KVM RJ-45 32 port Switch with with Combo PS/2 & USB interface, (*PS2 / USB Dongles are optional)

LCDK1060-d 1U Rackmount Keyboard Drawer with Compact keyboard and trackball , Lock, 2 Console (Local + IP ) CAT.5 IP KVM RJ-45 32 port Switch with Combo PS/2 & USB interface, (*PS2 / USB Dongles are optional)

LCDK1060-n 1U Rackmount Keyboard Drawer with Notebook keyboard and touchpad mouse, Lock, 2 Console (Local + IP ) CAT.5 IP KVM RJ-45 32 port Switch with Combo PS/2 & USB interface, (*PS2 / USB Dongles are optional)

LCDK1060-t 1U Rackmount Keyboard Drawer with Compact keyboard and touchpad mouse, Lock, 2 Console (Local + IP ) CAT.5 IP KVM RJ-45 32 port Switch with Combo PS/2 & USB interface, (*PS2 / USB Dongles are optional)

LCDK1060-b 1U Rackmount Keyboard Drawer with Notebookt keyboard and mini trackball mouse, Lock, 2 Console (Local + IP ) CAT.5 IP KVM RJ-45 32 port Switch with Combo PS/2 & USB interface, (*PS2 / USB Dongles are optional)
