1U Rackmount Monitor Keyboard Drawer with KVM Options
Model LCD1U19-32

NOVA 1U Rackmount 18" High Resolution 1920x1200 LED Monitor Keybaord Drawer
Optional Cat6 KVM, HDMI KVM ( 2K KVM ) , DVI KVM, VAG Combo KVM, VGA USB KVM with USB Hub,
Multi-User KVM: 2 / 3 / 4 Simultaneous Users, Matrix KVM, IP KVM
TAA Compliant

1U 18" 1920 x 1200 Monitor KVM Console LCD1U19-32

Features & Benefits

1U 18" Industrial Grade Ultra High Resolution LCD Console
1920 x 1200 WUXGA native resolution. Support Full HD with 1080p resolution
HDMI 1.4 + VGA Video Inputs
Short Depth design of 18.5"/470mm
Front panel with 2-point lock
SUN keyboard option is available
TAA Compliant

Options

Dual stereo speakers for HDMI
DP 1.0 + Speakers
DVI-D + Audio input & output + Speakers
3G / HD / SD-SDI Broadcast-grade input
2-post rack mounting option
Front USB hub port for device access
HDMI KVM / 2K KVM, DVI KVM, Combo KVM, USB KVM with USB Hub,
Multi-User KVM: 2 / 3 / 4 Simultaneous Users, Matrix KVM, IP KVM
250V , 125V , 110V , 48V, 24V or 12V DC power

LCD Screen
Display Size	18"
Panel Type	Industrial Grade High Resolution Wide Screen TFT LCD
Resolutions	Maximum Resolution up to 1920 x 1200
Viewing Angle	89/89/89/89 degree
Contrast Ratio	1000 : 1
Brightness	300 cd/m²
MTBF (hrs)	15,000
Colors	16.7 M
Video input	VGA + HDMI 1.4
Keyboard & Pointing Device
Model n / b	Standard Windows Keyboard with/ Numeric Keypad & Touchpad or Trackball
Model Sn / Sb (SUN)	Optional SUN Keyboard with HotKeys, Touchpad or Trackball
Power Supply
Input	Auto-sensing 100 to 240VAC, 50 / 60Hz
Environmental
Temperature	0 to 55 Degree Celsius (Operation) -20 to 60 Degree Celsius (Storage)
Relative Humidity	10~90%, non condensing(Operation) 5~90%, non condensing(Storage)
Attitude	16,000 ft (Operating) 40,000 ft (Non-Operating)
Shock	10G peak acceleration (11ms duration)
Vibration	10~300Hz, 0.5G RMS random vibration
Mechanical
Product Dimension	Single Console : 17.4W x 18.5D x 1.73H inch / 442W x 470D x 44H mm Console with KVM : 17.4W x 23.2D x 1.73H inch / 442W x 590D x 44H mm
Product Weight	Single Console : 26.4lbs Console with KVM: 29lbs
Compiancel
	FCC, CE CE / LVD & UKCA REACH & RoHS3 / WEEE TAA Compliant
SUN KVM
Please contact us for more information.

	Datat Sheet
	User Manual for Single Consolel LCD1U19-32

Free Ground Shipping. Learn More.

Optional KVM Switch	Number of User	Cascade Capacity	Number of KVM Port	Part Number	Product Sheet & User Manual for KVM Switch
Combo KVM / 1 User
Combo USB / PS2 KVM	1 Local User	Up to 8 level	8	LCD1U19-32-8KVM-n ( touchpad)	Product Sheet User Manual
				LCD1U19-32-8KVM-b ( trackball)
			8	LCD1U19-32-8KVM-n-u ( touchpad)
				LCD1U19-32-8KVM-b-u ( trackball)
			16	LCD1U19-32-16KVM-n-u ( touchpad)
				LCD1U19-32-16KVM-b-u ( trackball)
Combo KVM / 2 Users
Combo USB / PS2 KVM	1 Local User + 1 Extended User ( Via Cat6 )	Up to 8 level	8	LCD1U19-32-8KVM2-n ( touchpad)	Product Sheet User Manual
				LCD1U19-32-8KVM2-b( trackball)
			16	LCD1U19-32-16KVM2-n ( touchpad)
				LCD1U19-32-16KVM2-b ( trackball)
Combo USB / PS2 KVM	1 Local User + 1 Network IP User ( IP KVM)	Up to 8 level	8	LCD1U19-32-8KVM2IP-n ( touchpad)	Product Sheet User Manual
				LCD1U19-32-8KVM2IP-b( trackball)
			16	LCD1U19-32-16KVM2IP-n ( touchpad)
				LCD1U19-32-16KVM2IP-b ( trackball)
Cat6 KVM / 1 User
Cat6 KVM	1 Local User	Up to 8 level	8	LCD1U19-32-U8KVM-n ( touchpad)	Product Sheet User Manual
				LCD1U19-32-U8KVM-b ( trackball)
			16	LCD1U19-32-U16KVM-n ( touchpad)
				LCD1U19-32-U16KVM-b ( trackball)
			32	LCD1U19-32-U32KVM-n ( touchpad)
				LCD1U19-32-U32KVM-b ( trackball)
Cat6 KVM / 2 Users
Cat6 KVM	1 Local User + 1 Extended User ( Via Cat6 )	Up to 8 level	8	LCD1U19-32-U8KVM2-n ( touchpad)	Product Sheet User Manual
				LCD1U19-32-U8KVM2-b ( trackball)
			16	LCD1U19-32-U16KVM2-n ( touchpad)
				LCD1U19-32-U16KVM2-b ( trackball)
			32	LCD1U19-32-U32KVM2-n ( touchpad)
				LCD1U19-32-U32KVM2-b ( trackball)
Cat6 KVM	1 Local User + 1 Network IP User ( IP KVM)	Up to 8 level	8	LCD1U19-32-U8KVM2IP-n ( touchpad)	Product Sheet ) User Manual
				LCD1U19-32-U8KVM2IP-b ( trackball)
			16	LCD1U19-32-U16KVM2IP-n( touchpad)
				LCD1U19-32-U16KVM2IP-b ( trackball)
			32	LCD1U19-32-U32KVM2IP-n( touchpad)
				LCD1U19-32-U32KVM2IP-b ( trackball)
HDMI KVM ( 2K KVM) / 1 User
HDMI KVM / 2K KVM	1 Local User	1 level	8	LCD1U19-32-8HD-n ( touchpad)	Product Sheet User Manual
				LCD1U19-32-8HD-b ( trackball)
DVI KVM / 1 User
DVI KVM	1 Local User	1 level	12	LCD1U19-32-12DVI-n ( touchpad)	Product Sheet User Manual
				LCD1U19-32-12DVI-b ( trackball)
VGA USB KVM with USB Hub / 1 User
USB KVM with USB Hub	1 Local User	1 level	8	LCD1U19-32-H8KVM-n ( touchpad)	Product Sheet User Manual
				LCD1U19-32-H8KVM-b( trackball)
VGA USB KVM with USB Hub / 2 Users
USB KVM with USB Hub	1 Local User + 1 Extended User ( Via Cat6 )	1 level	8	LCD1U19-32-H8KVM2-n ( touchpad)	Product Sheet User Manual
				LCD1U19-32-H8KVM2-b ( trackball)
USB KVM with USB Hub	1 Local User + 1 Network IP User ( IP KVM)	1 level	8	LCD1U19-32-H8KVM2IP-n ( touchpad)	Product Sheet User Manual
				LCD1U19-32-H8KVM2IP-b( trackball)
Optional KVM Switch	Number of User	Cascade Capacity	Number of KVM Port	Part Number	Product Sheet & User Manual for KVM Switch
Matrix Combo KVM / 2 - 4 Users
Matrix VGA Combo KVM	1 Local User + 1 Extended User ( Via Cat6 )	Up to 8 level	8	LCD1U19-32-M82-n( touchpad)	Product Sheet User Manual
				LCD1U19-32-M82-b( trackball)
			16	LCD1U19-32-M162-n ( touchpad)
				LCD1U19-32-M162-b ( trackball)
	1 Local User + 2 Extended Users ( Via Cat6 )	Up to 8 level	8	LCD1U19-32-M83-n( touchpad)
				LCD1U19-32-M83-b( trackball)
			16	LCD1U19-32-M163-n ( touchpad)
				LCD1U19-32-M163-b ( trackball)
	1 Local User + 3 Extended Users ( Via Cat6 )	Up to 8 level	8	LCD1U19-32-M84-n( touchpad)
				LCD1U19-32-M84-b( trackball)
			16	LCD1U19-32-M164-n ( touchpad)
				LCD1U19-32-M164-b ( trackball)
Matrix VGA Combo KVM	1 Local User + 1 Extended User ( Via Cat6 ) + 1 Network IP User ( IP KVM)	Up to 8 level	8	LCD1U19-32-M83IP-n( touchpad)	Product Sheet User Manual
				LCD1U19-32-M83IP-b( trackball)
			16	LCD1U19-32-M163IP-n ( touchpad)
				LCD1U19-32-M163IP-b ( trackball)
	1 Local User + 2 Extended Users ( Via Cat6 ) + 1 Network IP User ( IP KVM)	Up to 8 level	8	LCD1U19-32-M84IP-n( touchpad)
				LCD1U19-32-M84IP-b( trackball)
			16	LCD1U19-32-M164IP-n ( touchpad)
				LCD1U19-32-M164IP-b ( trackball)
	1 Local User + 1 Extended User ( Via Cat6 ) + 2 Network IP Users ( IP KVM)	Up to 8 level	8	LCD1U19-32-M84IP2-n( touchpad)
				LCD1U19-32-M84IP2-b( trackball)
			16	LCD1U19-32-M164IP2-n ( touchpad)
				LCD1U19-32M164IP2-b ( trackball)

Other Options

Part Number	Description
Optional Keyboard & Pointing Devices
-Sn	Change Windows Keyboard to SUN keyboard with touchpad
-Sb	Change Windows Keyboard to SUN keyboard with trackball
Optional USB Port ( For Single Port Console Only)
-UH	Front USB Port ( * For Single Console Only )
Optional Video /Audio Inputs
-AU	2 x speaker for HDMI
-SDI	3G-SDI + Speaker + VGA + HDMI
-DVI	DVI-D + Audio + Speaker + VGA + HDMI
-DP	DP + Speaker + VGA + HDMI
Optional DC Power
-DC12	Change to 12V DC Power Input
-DC24	Change to 24V DC Power Input
-DC48	Change to 48V DC Power Input
-DC110	Change to 110V DC Power Input
-DC125	Change to 125V DC Power Input
-DC250	Change to 250V DC Power Input
Optional Dongle
LCD-A2001	VGA-USB Dongle
LCD-A2002	VGA-PS/2 Dongle
LCD-A2003	DVI-USB Dongle
LCD-A2004	HDMI -USB Dongle
LCD-A2005	DisplayPort -USB Dongle
LCD-A2006	USB-C / USB Dongle
Optional Cables
LCD-A3011	6-ft DVI-USB KVM cable
LCD-A3012	6-ft HDMI-USB KVM cable
LCD-A3004	6-ft DVI Console Cable
LCD-A3005	6-ft DVI KVM Cable
LCD-A3006	15-ft DVI KVM Cable
LCD-A3001	6-ft Combo PS/2 USB KVM Cable
LCD-A3002	10-ft Combo PS/2 USB KVM Cable
LCD-A3003	15-ft Combo PS/2 USB KVM Cable
LCD-A1014	6-ft USB 3-in-1 KVM Cable
LCD-A1015	10-ft USB 3-in-1 KVM Cable
LCD-A1016	15-ft USB 3-in-1 KVM Cable
LCD-A1019	6-ft Cascade Cable
